Home > products > Mud Pump Dampener > Drilling Mud Pump Rubber Dampener Bladder Temperature and Corrosion Resistance

Drilling Mud Pump Rubber Dampener Bladder Temperature and Corrosion Resistance

Product Details

Place of Origin: China

Brand Name: LONGWELL

Certification: API-7K

Model Number: Oil Drilling Mud Pump

Payment & Shipping Terms

Minimum Order Quantity: 1 PCS

Packaging Details: Plywood case/Iron pallet

Payment Terms: T/T 30%DP, balabce before ship

Supply Ability: 1000 PCS per Month

Get Best Price
Highlight:

Drilling Mud Pump Dampener Bladder

,

Temperature Resistance Dampener Bladder

,

Rubber Pulsation Dampener Bladder

Features:
High Pressure Resistance, Temperature Resistance, Corrosion Resistance
Temperature Rating:
150°F
Standard Or Nonstandard:
Standard
Oem:
Applicable
Mounting Type:
Horizontal
Material:
Rubber
Condition:
New
Connection Type:
Flanged
Pressure Rating:
5000 Psi
Pressure:
Low Pressure
Structure:
Piston Pump
Warranty:
1 Year
Usage:
Oil
BOMCO:
F800/1000/1300/1600/1600HL
HONGHUA:
3NB-800/1000/1300/1600F
HRSB:
RS-F800/1000/1300/1600
INGZHOU:
QF-1300/1600
LS-NOW:
3NB1300C/1600
NOV:
12-P-160 14-P-220
WeatherFord:
MP-10/16
GD:
PZ-7/8/9/10/11
EMSCO:
FB-1300/1600
RUSSIAN:
UNBT-950/1180L UNB-600 8T650
Features:
High Pressure Resistance, Temperature Resistance, Corrosion Resistance
Temperature Rating:
150°F
Standard Or Nonstandard:
Standard
Oem:
Applicable
Mounting Type:
Horizontal
Material:
Rubber
Condition:
New
Connection Type:
Flanged
Pressure Rating:
5000 Psi
Pressure:
Low Pressure
Structure:
Piston Pump
Warranty:
1 Year
Usage:
Oil
BOMCO:
F800/1000/1300/1600/1600HL
HONGHUA:
3NB-800/1000/1300/1600F
HRSB:
RS-F800/1000/1300/1600
INGZHOU:
QF-1300/1600
LS-NOW:
3NB1300C/1600
NOV:
12-P-160 14-P-220
WeatherFord:
MP-10/16
GD:
PZ-7/8/9/10/11
EMSCO:
FB-1300/1600
RUSSIAN:
UNBT-950/1180L UNB-600 8T650
Drilling Mud Pump Rubber Dampener Bladder Temperature and Corrosion Resistance

Suction dampener is a very effective aid for improving suction performance and eliminating fluid pulsations in the suction line, which results in a smoother flow in the discharge line.


The mounting for KB-75 pulsation dampener (1) is a flange with R-39 seal washer. Before installing dampener, thoroughly clean ring groove and ring, and after setting dampener into place, tighten the nut (8) with 950-1265N.m (700-935ft.lbs) torque. Tighten nuts in a criss-cross order.



Drilling Mud Pump Rubber Dampener Bladder Temperature and Corrosion Resistance 0


The discharge pulsation dampener is only allowed to charge nitrogen or air. No inflammable and explosive gases are allowed such as oxygen, hydrogen etc.


When stopping the pump check if the pre-charging pressure of discharge pulsation dampener meets the operational requirements.



Drilling Mud Pump Rubber Dampener Bladder Temperature and Corrosion Resistance 1
